HARDWARE AUTHENTICATION TOKENS

We offer a portfolio of practical, reliable and secure hardware tokens of different form factors and authentication methods that address all your needs for your users.



With Safewalk you can choose any software or hardware tokens OATH/HOTP or OATH/TOTP compliant that are not listed in our portfolio and that can be included upon request.



OATH (HOTP/TOTP) FLEX CARD

85.60 mm × 53.98 mm x 0.8 mm

(3.375 in × 2.125 in x 0.0315 in)

ISO7810

Press button to display 6/8 digits One-Time Password

HOTP  (Event-Based) RFC 4226

or

TOTP (Time-Based) RFC 6238

3 years with 23,000 operation cycles

or

5 years with 20,000 operation cycles

ISO7810, ISO14443, ISO 15693, CE, FCC, OATH, RoHS

1 year (can be extended to 3 years)

Provided in a white label format. Can be customized with artwork for an additional fee and an MOQ of 1000 units

DIMENSION
(LENGTH X WIDTH X HEIGHT)

USAGE

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

CUSTOMIZATION OPTIONS

OATH (HOTP/TOTP) FLEX CARD WITH PIN



85.60 mm × 53.98 mm x 0.8 mm

(3.375 in × 2.125 in x 0.0315 in)

ISO7810

13 buttons

(1 mechanical button and 12 capacitive touch buttons)

Enter PIN (numeric). Press button to display 8 digits One-Time Password

HOTP  (Event-Based) RFC 4226

or

TOTP (Time-Based) RFC 6238

ISO7810, ISO14443, ISO 15693, CE, FCC, OATH, RoHS

1 year (can be extended to 3 years)

A Personal Unlocking Key (PUK) is provided in case the card was locked due to too many wrong PIN entries

Provided in a white label format. Can be customized with artwork for an additional fee and an MOQ of 1000 units

DIMENSION
(LENGTH X WIDTH X HEIGHT)

KEYPAD

USAGE

ALGORITHM

COMPLIANCE & CERTIFICATIONS

WARRANTY

UNLOCKING MECHANISM

CUSTOMIZATION OPTIONS



OATH (HOTP) KEYFOB

62 mm × 29 mm x 11 mm

(2.441 in × 1.142 in x 0.433 in)

Press button to display 6 digits One-Time Password

HOTP  (Event-Based) RFC 4226

5 years

CE, FCC, OATH, RoHS

1 year (can be extended to 3 years)

DIMENSION
(LENGTH X WIDTH X HEIGHT)

USAGE

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

OATH (TOTP) KEYFOB



62 mm × 27 mm x 12 mm

(2.441 in × 1.062 in x 0.472 in)

Press button to display 6 digits One-Time Password

TOTP (Time-Based) RFC 6238

5 years

CE, FCC, OATH, RoHS

1 year (can be extended to 3 years)

DIMENSION
(LENGTH X WIDTH X HEIGHT)

USAGE

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

BIOPASS (FIDO) KEYFOB



42 mm × 30 mm x 10 mm

(1.653 in × 1.181 in x 0.394 in)

Windows, Linux, MacOS

FIDO U2F (Using SHA256 with ECDSA on P-256)

USB connected (no charge)

CE, FCC, FIDO, RoHS

DIMENSION
(LENGTH X WIDTH X HEIGHT)

USAGE

USB-A

HID

SUPPORTED OPERATING SYSTEM

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

1 year (can be extended to 3 years)

42 mm × 30 mm x 10 mm

(1.653 in × 1.181 in x 0.394 in)

Windows, Linux, MacOS

FIDO U2F (Using SHA256 with ECDSA on P-256)

USB connected (no charge)

CE, FCC, FIDO, RoHS

DIMENSION
(LENGTH X WIDTH X HEIGHT)

FINGERPRINT MODULE

USB-A

HID

SUPPORTED OPERATING SYSTEM

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

1 year (can be extended to 3 years)



WIRELESS (FIDO) KEYFOB

47 mm × 30 mm x 8 mm

(1.850 in × 1.181 in x 0.315 in)

Windows, Linux, MacOS

FIDO U2F (Using SHA256 with ECDSA on P-256)

USB connected (no charge)

CE, FCC, FIDO, RoHS

DIMENSION
(LENGTH X WIDTH X HEIGHT)

NFC

BLE

USB-A

SUPPORTED OPERATING SYSTEM

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

HID

WARRANTY

1 year (can be extended to 3 years)

WIRELESS (FIDO) KEYFOB TOUCH



44 mm × 20 mm x 4 mm

(1.733 in × 0.787 in x 0.157 in)

Windows, Linux, MacOS

FIDO U2F (Using SHA256 with ECDSA on P-256)

HOTP  (Event-Based) RFC 4226

USB connected (no charge)

CE, FCC, FIDO, RoHS

1 year (can be extended to 3 years)

DIMENSION
(LENGTH X WIDTH X HEIGHT)

NFC

USB-A

HID

SUPPORTED OPERATING SYSTEM

ALGORITHM

BATTERY LIFETIME

COMPLIANCE & CERTIFICATIONS

WARRANTY

DOWNLOAD SAFEWALK DATASHEET
